Art. No. 4403195
IMS TLS E/24
Smart Euro bottle dispensers for soaps and hand disinfectants
- Description
- Documents
- Technical Drawings
- Accessories
- Spare parts
ingo-man smart IMS TLS E/24, soap and disinfectant dispenser, for 1000 ml standard Euro bottles, long operating stainless steel lever, brushed stainless steel housing, exchangeable stainless steel pump 24 with bent suction tube, different dosage adjustments (approx. 0.75/ 1.0/ 1.2/ 1.5 ml/stroke), 1 bottle HDPE, with intelligent face shield that enables WiFi communication with KANARY, the unit automatically records hand hygiene events (dosage, timestamp, dispenser ID) and sends that data to a central database for evaluation, gives immediate feedback on performance through an integrated LED, A separate integrated LED informs users when the battery is low
- with lithium metal battery type ER 26500
- Transport Code: 3091
- Hazardous material class: 9
| Marke: | ingo-man® smart |
|---|---|
| Product type: | Hygiene dispenser |
| Dispenser type: | Euro bottle dispenser |
| Type of operation: | Long operating stainless steel lever, Stainless steel lever |
| Housing: | Stainless steel, brushed |
| Face shield: | Plastic, white |
| Filling volume (ml): | 1000 ml |
| Material: | Stainless steel |
| Dosierpumpe: | long-life stainless steel pump with bent suction tube |
| Dosage quantity: | 0.75 / 1.0 / 1.2 / 1.5 ml/stroke |
| Filling good: | Disinfectant, Liquid soaps |
| Smart-Funktion: | Smart |
| Abschließbar: | No |
| mit Abtropfschale: | No |
| Battery: | Lithium battery ER26500 (Transport Code: 3091; Hazardous material class: 9), 3.6 V, 9.0 Ah, exchangeable, non-rechargeable, confected battery with cable and plug can be reordered |
| Electronic: | Board with sensors, WiFi module 802.11 b/g/n (Frequency range: 2400 MHz - 2483.5 MHz; WPA and WPA2) and NFC Chip (Frequency: 13.56 MHz) |
| Firmware: | Updates and configuration “over-the-air” (OTA) |
| Software: | Dispenser with integrated Smart Module enables automatic fill level detection and connection to KANARY as well as third-party platforms |
| Wall plate: | Standard ingo-man® plastic wall plate |
| Montage: | Wall mounting with 3 screws and wall plugs |
| Cleaning: | manual wipe disinfection, not dishwashersafe, not autoclavable |
