Art. No. 1423633
TTU 2 P AW SMART
Intelligent toilet paper dispenser with ergonomic toilet paper dispensing
- Description
- Documents
- Technical Drawings
- Spare parts
SanTRAL® Plus TTU 2 P Arctic White (AW) SMART, toilet paper dispenser for 2 standard toilet paper rolls, stainless steel, white powder coated (RAL 9016 Traffic White), lockable, automatic reloading of second roll when first roll is emptied, with window for fill level control, sloped-top housing prevents placement of unwanted objects on dispenser
Data transmission via WiFi with visualization by KANARY or third party platforms, for fully automatic detection of the fill level via sensor technology, integrated LEDs to indicate a critical battery and fill level, over-the-air configuration and firmware update, NFC to read out data and to configure via smartphone.
| Brand: | SanTRAL® Plus |
|---|---|
| Quantity / Pallet EU: | 136 |
| Product Type: | Toilet paper dispenser |
| Housing: | Stainless steel, white powder-coated (RAL 9016 Traffic White) |
| Material: | Stainless steel |
| Filling volume (Toilet paper): | 2 standard rolls (max. roll diameter 120 mm) |
| Smart function: | Smart |
| Lockable: | Yes |
| Lock: | SanTRAL vandalism-proof lock, plastic |
| Batteries: | 4x AA alkaline batteries, 1.5 V, exchangeable, non-rechargeable |
| Electronic: | Board with sensors, WiFi module 802.11 b/g/n (Frequency range: 2400 MHz - 2483.5 MHz; WPA and WPA2) and NFC Chip (Frequency: 13.56 MHz) |
| Firmware: | Updates and configuration “over-the-air” (OTA) |
| Voltage: | 6 Volt |
| Compliancy: | RoHS |
| CE certification: | EN 300328 Integration verification WLAN, EN 300330 Integration verification NFC, ETSI EN 62311.2008 EMF, ETSI EN 301489-1 EMV |
| Software: | Dispenser with integrated Smart Module enables automatic fill level detection and connection to KANARY as well as third-party platforms |
| Mounting: | Wall mounting with 4 screws and wall plugs |
| Cleaning: | manual wipe disinfection, not dishwashersafe, not autoclavable |
| Warranty: | 5 years |
