Art. No. 1423633


Intelligent toilet paper dispenser with ergonomic toilet paper dispensing

MaterialLockSmart Technology
  • Description

    SanTRAL® Plus TTU 2 P Arctic White (AW) SMART, toilet paper dispenser for 2 standard toilet paper rolls, stainless steel, white powder coated (RAL 9016 Traffic White), lockable, automatic reloading of second roll when first roll is emptied, with window for fill level control, sloped-top housing prevents placement of unwanted objects on dispenser

    Data transmission via WiFi with visualization by KANARY or third party platforms, for fully automatic detection of the fill level via sensor technology, integrated LEDs to indicate a critical battery and fill level, over-the-air configuration and firmware update, NFC to read out data and to configure via smartphone.

    Battery:4x AA alkaline batteries, 1.5 V, exchangeable, non-rechargeable
    CE certification:EN 300328 Integration verification WLAN, EN 300330 Integration verification NFC, ETSI EN 62311.2008 EMF, ETSI EN 301489-1 EMV
    Electronic:Board with sensors and WiFi module 802.11 b/g (WPA and WPA2)
    Firmware:Updates and configuration “over-the-air” (OTA)
    Housing:Stainless steel, white powder-coated (RAL 9016 Traffic White)
    Lock:SanTRAL vandalism-proof lock, plastic
    Mounting:Wall mounting with 4 screws and wall plugs
    Software:Dispenser with integrated Smart Module enables automatic fill level detection and connection to KANARY as well as third-party platforms
    Voltage:6 Volt
    Warranty:5 years
    Product Sub-Categories:Toilet paper dispenser
    Cleaning Method:manual wipe disinfection
    Filling Volume (Toilet Paper):2 standard rolls (max. roll diameter 120 mm)
    Material:Stainless steel
    Smart Technology:Smart
  • Documents

  • Technical Drawings
