Art. No. 1424555
Kanary Gateway EU
LTE router for a secure connection between the smart dispenser systems and the Kanary Cloud
- Description
- Documents
The Kanary Gateway provides a secure connection between OPHARDT smart devices and the Kanary Cloud. It is compatible with the ingo-man® smart and the SanTRAL® Plus SMART dispensers. For installation, the gateway only needs to be plugged into the power socket. After that, the connection between the smart dispensers and the Kanary Cloud is set up automatically. The Kanary gateway eliminates the need for configuration with the local WLAN network. It works via mobile radio and the SIM card is included in the delivery. Connection with up to 32 devices simultaneously possible.
Manufacturer: ZTE
Marke: | Kanary |
---|---|
Power supply: | 1x SIM Slot (3FF); 1x AC (Europe Standard) |
Product type: | LTE Router |
Material: | Plastic |
Technologie: | ASR1826 + QCA6174 |
Mobilfunk-WAN: | FDD/TDD/UMTS/GSM |
Konfiguration der Bandbreite: | DC-HSPA+ / HSPA / UMTS Band 1,8, EDGE/GPRS/GSM Quad Bands, LTE FDD Band 1,3,7,20, LTE TDD Band 38 |
2CA: | B1+B3; B1+B7; B1+B20; B3+B7; B3+B20; B7+B20 |
Maximale Datenübertragungsrate: | DC-HSPA+: DL/UL 42/5.76Mbps, FDD-LTE: DL/UL 300/50Mbps (CAT6), TDD-LTE: DL/UL220+/11+Mbps (CAT6) |
Wi-Fi: | 802.11 a/b/g/n/ac, 2.4 GHz 2x2 / 5 GHz 2x2; up to 32 users supported |
